Part Number DC Spark-over Voltage 100V/s(V)Impulse Voltage1000V/us(V)Impulse Current 8/20μs(KA)Capacitance 0.5V 1MHZ(pF)Size L*W*H(mm) 搜索

BL075N 75V ≤650V 1KA ≤0.5pf 2.9*2.1*1.9
BL091N 90V ≤650V 1KA ≤0.5pf 2.9*2.1*1.9
BL801M 800V ≤1300V 1KA ≤0.5pf 2.9*2.1*1.9
BZ091N 90V ≤700V 1KA ≤0.5pf 3.2*2.5*2.5
BZ801M 800V ≤1300V 1KA ≤1pf 3.2*2.5*2.5
BC091N 90V ＜650V 2KA ≤1pf 4.5*3.2*2.7
BC091N-H 90V ＜650V 3KA ≤0.5pf 4.5*3.2*2.7
BC151N 150V ＜750V 2KA ≤1pf 4.5*3.2*2.7
BC201N 200V ≤800V 2KA ≤1pf 4.5*3.2*2.7
BC301N-D 300V ≤750V 2KA ≤1pf 4.5*3.2*2.7
BC401M 400V ≤950V 2KA ≤1pf 4.5*3.2*2.7
BC601N 600V ≤1200V 2KA ≤1pf 4.5*3.2*2.7
BC1000 1000V ≤1500V 2KA ≤1pf 4.0*3.2*2.7
BC1500 1500V ≤2200V 2KA ≤1pf 4.0*3.2*2.7
BC2000 2000V ≤2500V 2KA ≤1pf 4.5*3.2*2.7
BC3600 3600V ≤4700V 2KA ≤1pf 4.5*3.2*2.7
BF091N 90V ≤650V 5KA ≤1pf 4.2*5.0*5.0
BF801M 800V ≤1600V 3KA ≤1pf 4.2*5.0*5.0
BF102M 1200V ≤1800V 3KA ≤1pf 4.2*5.0*5.0
BF122M 1200V ≤2000V 3KA ≤1pf 4.2*5.0*5.0
